Conventional -Planetary Shaft
The planetary shaft in the planetary reducer is the assembly that connects the planetary wheel, which supports and holds the planetary wheel so that it can rotate around the Sun wheel. Planetary shaft is one of the main components of planetary gear transmission, and its structure design and manufacture have a great impact on the load distribution among the planetary wheels and the bearing capacity, noise and vibration of the transmission. Its common structural forms have two side plate integr...
- 1. Face Milling
- 2. Shoulder Milling
- 3. Hole Making
- 4. Boring
SNE(M)U+MFB145&245&275&288
1.The insert is with thickening double face negative eight edges design, good strength, stable processing
2.There are different cutting edge angles of 45°/75°/88°/ R radius
3.Suitable for the semi-finishing and roughing face milling of steel and cast iron
 |
 |
 |
 |
 |
APK(E)T+MEB190
1.The edge is with curve type design to decrease the cutting resistance.
2.Match with corn milling cutter holder, with high milling efficiency.
3.Suitable for semi-finishing and roughing machining of steel, stainless steel, cast iron and aluminum alloy.
|
|
|
|
|
D938
Suitable for efficient Drilling of Steel, Cast Iron and Stainless steel
|
|
|
GBR-FB Series Large Diameter Fine Boring Cutter
Suitable for fine boring of φ2.0mm-φ3300.0mm steel, cast iron and stainless steel
GBR-RB Series Large Diameter Rough Boring Cutter
Suitable for rough boring of φ2.0mm-φ3300.0mm steel, cast iron and stainless steel
